Opto Splitter RDM DMX

The Elation RDMXM1 Opto Splitter is a rackmount 6-way RDM/DMX data splitter designed for clean, reliable signal distribution in professional lighting systems. It provides one locking 5-pin DMX input, a locking 5-pin DMX loop thru with built-in termination, and six opto-isolated 5-pin DMX outputs in a rugged die-cast aluminum housing.

• 6-way RDM/DMX data splitter for professional lighting control networks
• RDM E1.20 compliant for supported remote device management workflows
• Locking 5-pin DMX input and locking 5-pin DMX loop thru output
• Built-in termination on the DMX loop thru output
• 6 locking opto-isolated 5-pin DMX outputs
• Single unit 19" rack mounting kit for rackmount installation
• Universal multi-voltage auto switching power supply
• Die-cast aluminum housing for production use

• Product Type: 6-way RDM/DMX data splitter
• Model: RDMXM1
• Compliance: RDM E1.20 Compliant
• DMX Input: Locking 5pin DMX Input
• DMX Loop Thru: Locking 5pin DMX Loop Thru Output w/Built-In Termination
• DMX Outputs: 6 locking 5pin Opto-Isolated DMX Outputs
• Power Connector: Locking power connector In
• Power Supply: Universal Multi-Voltage Auto Switching Power Supply
• Input Voltage: AC 100-240V - 50/60Hz
• Max Power Consumption: 3W
• Operating Temperature: 14°F to 113°F (-10°C to 45°C)
• Length: 6.8" (173mm)
• Width: 19" (483mm)
• Vertical Height: 1.7" (44mm)
• Weight: 2.1 lbs. (1.0kg)

Ideal for touring racks, theaters, houses of worship, live venues, broadcast studios, rental systems, and permanent lighting installations that need reliable rackmount DMX and RDM signal distribution.
