Overview
When you're lighting a stage exposed to weather, dirt or travel, you need fixtures that don't blink. The ACME Lyra delivers 35,000 lumens of clean, high-output light from a 1,000W white LED engine—all sealed in an IP66-rated body that’s built to tour.
This isn’t a stripped-down weatherproof unit: Lyra brings full CMY plus linear CTO color control, dual gobos, dual prisms, framing shutters, animation effects, and a wide zoom range. It’s as flexible as it is powerful.
Watch It in Action
Top Features
- All-weather build: IP66-rated housing keeps rain, dust and debris out
- Serious output: 35,000 lumens at 8,000K native color temp
- Full feature set: CMY plus CTO, dual prisms, dual gobo wheels, frost, animation and more
- Flexible beam: 6° to 50° zoom with motorized focus and iris
- Framing system: 4-blade shutters with ±60° rotation for precision cuts
- Tour-ready hardware: Sealed power and data, auto-correcting pan and tilt, 92 lb chassis
Ideal for These Applications
- Outdoor festivals and concerts
- Themed environments and architectural installs
- Theatre and touring shows with mixed venue conditions
- Permanent rigs needing low-maintenance weather resistance
Tech Specs at a Glance
- Light source: 1,000W white LED engine (8,000K native)
- Output: 35,000 lumens (Ra>70), 25,600 lumens (Ra>90)
- IP rating: IP66
- Color system: CMY plus linear CTO (2,700K–6,500K)
- Color wheel: 5 colors, CRI, frost, open
- Gobos: 7 rotating, 9 static
- Prisms: 4-facet circular and 4-facet linear (combinable)
- Framing: 4 blades, ±60° rotation
- Zoom range: 6°–50°
- Focus/iris: Motorized focus and linear iris
- Control: DMX512, RDM | 5 DMX modes | 22–40 channels
- Power input: 100–240 V AC
- Power draw: 1,190 W
- Weight: 42 kg (92.6 lbs)
Built to Handle It All
The Lyra is a fixture you can count on when the weather turns or the schedule shifts. If your next job needs flexible features with zero compromise on protection, this is your go-to.
In Stock & Standing By
Professionally maintained, weather-ready, and available now from Christie Lites Used Gear.
